BENCH
GRINDING MACHINES
Manufacturers,
Exporters & Suppliers of all kinds of Bench Grinding Machines... |
| |
 |
Bench
Grinding Machine with Pedestal |
|
|
|
Manufactured by "Prem Brothers" Since
1959 |
"POWER
MASTER"
Double ended Heavy Duty Bench Grinding
Machines with Pedestals. These grinders
are Industrial Duty Grinders complete
with inbuilt drive suitable for operation
on AC 415 Volts Phase or 220 / 230 V Single
Phase, 50 Cycles Supply. Each grinder
is complete with two grinding wheels.
One fine & one coarse, two wheel Guards
with exhaust outlets, two adjustable tools
rests, rotary switch, condenser (only
in single phase) in the base and connecting
cable or terminal block.
"manufacturers,
suppliers, wholesaler and exporters
of Pedestal Bench Grinding Machine."
|
| |
| |
| |
|
Technical
Specifications
S.No. |
Model |
Wheel
Size
Dia. x Width x Bare |
KW-HP |
A |
B |
C |
D |
E |
F |
G |
H |
I |
J |
1 |
1678 |
150
x 20 x19.05 |
0.25-0.33 |
265 |
580 |
465 |
165 |
230 |
175 |
205 |
175 |
205 |
7.93 |
2 |
1678 |
200
x 25 x 19.05 |
0.37-0.50 |
295 |
580 |
470 |
165 |
285 |
175 |
205 |
175 |
205 |
7.93 |
3 |
101 |
200
x 25 x 25.40 |
0.75-1.00 |
330 |
735 |
610 |
203 |
285 |
245 |
280 |
172 |
255 |
12.70 |
4 |
101 |
250
x 25 x 25.40 |
0.75-1.00 |
365 |
735 |
610 |
203 |
360 |
245 |
280 |
172 |
255 |
12.70 |
|
| |
|
Bench
Grinding Machine with Pedestal |
|
|
Manufactured by "Prem Brothers" Since
1959
|
"POWER
MASTER" Double ended Heavy
Duty Bench Grinding Machines with Pedestals.
These grinders are Industrial Duty Grinders
complete with inbuilt drive suitable for
operation on AC 415 Volts Phase or 220
/ 230 V Single Phase, 50 Cycles Supply.
Each grinder is complete with two grinding
wheels. One fine & one coarse, two
wheel Guards with exhaust outlets, two
adjustable tools rests, rotary switch
condenser (only in single phase) in the
base and connecting cable or terminal
block.
"manufacturers,
suppliers, wholesaler and exporters of
Bench Grinding Machine with Pedestal"
|
| |
| Technical
Specifications |
S.No.
|
H.P |
Model |
Wheel
Size
(Dia. x Widht x Bore |
Spindle
RPM |
1 |
0.33
|
1678 |
150
x 20 x 19.05 |
2800 |
2 |
0.50 |
1678 |
200
x 25 x 19.05 |
2800 |
3 |
0.75 |
1678 |
200
x 25 x 19.05 |
2800 |
4 |
1.00 |
101 |
200
x 25 x 25.40 |
2800 |
5 |
1.00 |
101 |
250
x 25 x 25.40 |
2800 |
6 |
2.00 |
1012 |
250
x 25 x 25.40 |
2800 |
|
|
| |
|
Heavy
Duty Bench Grinding Machine with Pedestal |
|
|
 Manufactured
by "Prem Brothers" Since 1959
|
"POWER
MASTER" Double ended Heavy
Duty Bench Grinding Machines with Pedestals.
These grinders are Industrial Duty Grinders
complete with inbuilt drive suitable for
operation on AC 415 Volts Phase, 50 Cycles
Supply. Each grinder is complete with
two grinding wheels. One fine & one
coarse, two wheel Guards with exhaust
outlets, two adjustable tools rests, rotary
switch in the base and terminal block.
"manufacturers,
suppliers, wholesaler and exporters of
Bench Grinding Machine with Pedestal"
|
| |
| Technical
Specifications |
S.No.
|
H.P |
Model |
Wheel
Size
(Dia. x Widht x Bore |
Spindle
RPM |
1 |
2.00 |
123 |
300
x 40 x 38.10 |
1440 |
2 |
2.00 |
123 |
300
x 50 x 38.10 |
1440 |
|
|
| |
|
Heavy
Duty Bench Grinding Machine with Pedestal |
|
|
Manufactured by "Prem Brothers" Since
1959 |
"POWER
MASTER" Double ended Heavy
Duty Bench Grinding Machines mounted on
steeel fabricated Pedestals. These machines
are directly driven by and inbuilt drive
and complete with Starter, Two Grinding
Wheels, two Heavy Duty M.S. Wheel Guards
and tool rests.
Packing charges will be extra.
"manufacturers, suppliers, wholesaler
and exporters of Heavy Duty Bench Grinding
Machine with Pedestal" |
| |
| Technical
Specifications |
S.No. |
Wheel
Size |
HP |
RPM |
Center
Height (mm) |
Model |
10 |
14"
x 2" |
3.0 |
1440 |
915 |
314 |
11 |
16"
x 2" |
3.0 |
1440 |
915 |
316 |
12 |
18"
x 2" |
5.0 |
1440 |
915 |
518 |
|
|
 |
| |
|
Bench
Grinder with Built in Dust Collectors |
|
|
Model - 1678- 0.75- 2
Manufactured by "Prem Brothers" Since
1959 |
"POWER
MASTER" Bench Grinders with
Built in Dust Collectors are specially
designed for Collection of dust generated
during Grinding Process.
Features
1) Bench Grinding Machine mounted on Rigid
steel Frame.
2) Low Noise : Below allowable noise level.
3) High Filtering efficiency even for
the finest dusts.
4) Total Security with :Cotton Filtering
sleeves (Non- inflammable)
5) Energy Savings : Low power consumption.
"manufacturers, suppliers, wholesaler
and exporters of Bench Grinder with built
in Dust Collector" |
| |
| Technical
Specifications |
Grinder
Motor |
0.55
KW , 0.75 HP, 3 Phase , 2800 RPM |
Wheel
Size |
200
x 25 x 31.75 mm (8") |
Dust
Collector Motor |
0.37
KW , 0.5 HP, 3 Phase |
CFM |
125 |
Shaker |
Manual |
Over
all Dim: |
L
x W x H
650 x 650 x 1050 |
Approx
Weight |
180
KG. |
|
|
| |
|
Heavy
Duty Grinder with Built in Dust Collector |
|
|
Manufactured by "Prem Brothers" Since
1959 |
"Power
Master" Heavy Duty Bench Grinders
with Built in Dust Collectors are specially
designed for collection of dust generating
during the grinding process. These are
mounted on a rigid steel frame. This machine
is directly driven by heavy duty Drive
2.2 KW 3 H.P, 3 Phase 50 cycles, 1440
RPM complete with starter, Two Grinding
Wheels 14" x 2" Aluminium Oxide,
heavy duty M.S Wheel Guards, Job Rests.
Dust Collecter Motor 1.5 H.P 3 Phase.
Dust Collector is fitted with a manual
shaker. Dust Drawer, Big Filters, 2 Nos.
Suction Inlet dia. 100 mm I.D Model -
BIDC-314.
Dust Collector have high filtering efficiency
to enable it to grasp even the finest
dust particles. Cotton filtering sleeves
provide it with total security against
inflammation. Other size of Grinders available
on request.
Wide range of Machines available
to suit different job requirements
|
| |
| |
| |
|
| |
|
Heavy
Duty Grinder with Built in Dust Collector
(With Control Panel) |
|
|
Manufactured by "Prem Brothers" Since
1959 |
|
| |
| NOTE:
We reserve the right to change. |
| Due
to constant improvement, techincal specifications
and dimensions are subjects to modification without
prior notice. |
